2J11 Deformable Permanent Magnetic Alloy Curie Temperature 860 °C

  • 2J11 Deformable Permanent Magnetic Alloy Curie Temperature 860 °C
Place of Origin China
Brand Name XUNSHI
Certification ISO 9001:2015
Model Number 2J11
Minimum Order Quantity 20kg
Price Negotiable
Packaging Details Plywood case
Delivery Time 45-60 days
Payment Terms T/T, Western Union
Supply Ability 300 kg per week
Product Details
Form Of Supply Cold Rolled Strip Thickness 0.05-1.0mm
Width 5-200mm Product Name Permanent Magnet Alloy
Spec GB/T 14988-2008 Curie Temperature 860 °C
High Light

Deformable Permanent Magnet Alloy

,

1.0mm Thickness Permanent Magnet Alloy

,

Cold Rolled Strip Permanent Magnet Alloy
Leave a Message
Product Description

2J11 Deformable Permanent Magnetic Alloy Curie temperature 860 °C



2J11 is a deformable permanent magnet alloy with good plasticity and can be made to the forging, rolling, pulling and cutting,

The 2J11 permanent magnet alloy can be made into thin sections or complex shaped parts with different magnetic and high mechanical properties.

The 2J11 alloy has good hysteresis performance within 2~5kA/m and good processing performance before tempering. Changing the tempering temperature can change the working magnetic field in a wide range.

Product Name Permanent Magnet Alloy
Grade 2J11
Form of supply Cold rolled strip
Thickness 0.05-1.0mm
Width 5-200mm
Spec GB/T 14988-2008

Physical properties

Density:8.1g/cm3

Melt temperature: 1530 °C-1600 °C

Curie temperature : 860 °C

Restivity: 0.77 Ω·

Good corrosion resistance and not rust in the atmosphere

Chemical composition of 2J11 (%, weight)

C ≤0.12
P ≤0.025
S ≤0.020
Si ≤0.70
Mn ≤0.70
Co 51.0~53.0
V 10.5-11.5
Ni ≤0.70
Fe Balance

Applications

Magnetic motor rotor, Magnetic brake

Forms of available

Cold-rolled strip without heat treatment

Thickness: 0.05-1.0mm

Width: 5-200mm



2J11 Deformable Permanent Magnetic Alloy Curie Temperature 860 °C 02J11 Deformable Permanent Magnetic Alloy Curie Temperature 860 °C 12J11 Deformable Permanent Magnetic Alloy Curie Temperature 860 °C 2
