Fecrco Permanent Magnet Alloy Mechanical Workability Hot Rolled Bar Auto Ammeter

Place of Origin China
Brand Name XUNSHI
Certification ISO 9001:2015
Model Number 2J85
Minimum Order Quantity 30kg
Price Negotiable
Packaging Details Plywood case
Delivery Time 40-45 days
Payment Terms T/T
Supply Ability 300 kg per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Equal Grade CKSR550(Japan) Forms Of Supply Cold Rolled Strip, Hot Rolled Bar, Hot Rolled Plate/strip, Forged Bar, Cold Drawn Wire
Similar Grades 2J83, 2J84 Certification ISO 9001:2015
Product Name Permanent Magnet Alloy Package Plywood Case
High Light

cobalt iron alloy

,

magnetic materials

,

Hot Rolled Bar Permanent Magnet Alloy

Leave a Message
Product Description

Fe-Cr-Co Permanent Magnet Alloy with Good Mechanical Workability





2J85 is a new type of permanent magnet. The properties of 2J85 are comparable to those of cast Al-Ni-Co magnets while it has a good ductility in the as-quenched state.

2J85 is specially suitable for making small and thin elements with accurated dimensions and complicated shapes.



Specification: YB/T 5261-2016 Wrought Iron-Chromium-Cobalt Permanent Magnet Alloys



Chemical composition

Element C Mn S P Cr Co Si Fe
Weight(%) 0.03 max. 0.20 max. 0.02 max. 0.02 max. 23.5~25.0 11.5~13.0 0.80~1.10 Balance



Application



Automobile odometer

Auto ammeter

Induction meters in automobile

Hearing-aid

Theodolite

Forest compass

Relay

Internal magnetic loudspeaker

Nautical magnetic compass

Magnetization economizer

Railway signal instrument

Linear motor

Water level switch of industrial automatic washing machine

Flowmeter in dairy industry

DC motor stator

Magnetic balance attractor

Kilowatt-hour meter

Oil field downhole locator

Low speed permanent magnet motor

Automatic instrument

Electromagnetic Matrix Display System

Constant temperature control instrument

Magnetic mixer

Micro stepping motor rotor

Hysteresis motor
