0.05~3.0mm 2J33 Permanent Magnetic Alloy Cold Drawn Wire for Recording Material

0.05~3.0mm 2J33 Permanent Magnetic Alloy Cold Drawn Wire for Recording Material
0.05~3.0mm 2J33 Permanent Magnetic Alloy Cold Drawn Wire for Recording Material 0.05~3.0mm 2J33 Permanent Magnetic Alloy Cold Drawn Wire for Recording Material

Large Image :  0.05~3.0mm 2J33 Permanent Magnetic Alloy Cold Drawn Wire for Recording Material

Product Details:

Place of Origin: China
Brand Name: AIWEN
Certification: ISO 9001:2015
Model Number: 2J33

Payment & Shipping Terms:

Minimum Order Quantity: 30kg
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 45-50 days
Payment Terms: T/T
Supply Ability: 200 kg per week
Detailed Product Description
Spec: GB/T 14989-2015 Diameter: 0.05~3.0mm
Forms Of Supply: Cold Drawn Wire, Cold Rolled Strip Hc: 31.84 KA/m
Br: 0.70 T Br·Hc: 23.88 KJ/m3
High Light:

precipitation hardening alloys

,

cobalt iron alloy

2J33 Permanent-Magnet Alloy Cold Drawn Wire for Recording Material





A-ONE ALLOY is able to produce 2J33 permenent magnet alloy in forms of wire, strip or per customer requirement.

2J33 is used to make small section permanent magnet and recording material.



Forms available: cold drawn wire and cold rolled strip



Size range:

Wire diameter: 0.05~3.0mm

Strip thickness: 0.20~1.00mm



Chemical composition

Element C Si Mn P S Ni Co V Fe
Weight(%) 0.12 max. 0.50 max. 0.50 max. 0.025 max. 0.020 max 0.70 max. 51.0~53.0 11.8~12.7 Balance



Delivery condition: without heat treatment



The parts should be heat treated after they are processed to get required magnetic properties.



Magnetic properties(after heat treatment)

Form Cold drawn wire Cold rolled strip
Parameter

Hc

(kA/m)

Br

(T)

Br·Hc

(kJ/m3)

Hc

(kA/m)

Br

(T)

Br·Hc

(kJ/m3)

Value 31.84 min. 0.70 min. 23.88 min. 27.86 min. 0.60 min. 18.31 min.



Heat treatment

Grade Temperature(°C) Duration(min) Cooling
2J33 580~640 20~60 air cool
