Higher Yield Strength Nickel Cobalt Alloy GH4738 Precipitation Hardened Superalloy

China Higher Yield Strength Nickel Cobalt Alloy GH4738 Precipitation Hardened Superalloy supplier
Higher Yield Strength Nickel Cobalt Alloy GH4738 Precipitation Hardened Superalloy supplier Higher Yield Strength Nickel Cobalt Alloy GH4738 Precipitation Hardened Superalloy supplier

Large Image :  Higher Yield Strength Nickel Cobalt Alloy GH4738 Precipitation Hardened Superalloy

Product Details:

Place of Origin: China
Brand Name: AIWEN
Certification: ISO9001
Model Number: GH4738

Payment & Shipping Terms:

Minimum Order Quantity: 100kg
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 45-50 days
Payment Terms: T/T
Supply Ability: 500kg per week
Contact Now
Detailed Product Description
Working Temperature: 815°C Equal Grades: WASPALOY, GH738
Density: 8.22g/cm3 Melting Range: 1330~1360°C
Form Of Supply: Hot Rolled Plate, Cold Rolled Plate, Pipe, Strip, Wire, Forging, Casting , Fastner Product Name: Nickel Cobalt Alloy

GH4738 is a Ni-Cr-Co based precipitation hardened superalloy.



GH4738 has higher yield strength and fatigue resistance during 760°C~870°C.It has good oxidation resistance and corrosion resistance in a gas turbine atmosphere at 870 degree C.It has good ductility and stable properties. It is suitable for making turbine disk, working blade, high temperature fastener, flame tube, shaft and turbine brake.



Chemical composition



Element C Cr Ni Co Mo Al Ti Fe
Weight(%) 0.03~0.10 18.0~21.0 Rem 12.0~15.0 3.50~5.00 1.20~1.60 2.75~3.25 2.00 max
Element B Zr Mn Si P S Cu
Weight(%) 0.003~0.010 0.020~0.080 0.10 max 0.015 max 0.015 max 0.015 max 0.100 max



The alloys have good oxidation resistance and corrosion resistance in various atmospheres encountered in jet engines or similar working conditions. Continuous operation of the antioxidant temperature up to 1040°C. Intermittent operation of the antioxidant temperature up to 870°C.



Forms of supply

Cold drawn bar

Hot rolled bar

Cold drawn wire

Hot rolled plate

Cold rolled plate

Cold rolled strip

Hot forged bar

Hot fored plate, ring
