N09902 Constant Elastic Alloy Cold Rolled Strip minimum thickness 0.04mm Ni-Span-C Alloy 902

N09902 Constant Elastic Alloy Cold Rolled Strip minimum thickness 0.04mm

N09902 is a heat treatable alloy designed primarily to obtain a constant modulus of elasticity in a useful temperature range of -40°C to 100°C. The addition of titanium to the nickel-chromium-iron alloy makes it hardenable by precipitation. It has outstanding properties of elastic modulus control and high strength, combined with unusually low drift and mechanical hysteresis.

Chemical Composition

• Nickel: 41.0-43.5
• Chromium: 4.90-5.75
• Titanium: 2.20-2.75
• Aluminum: 0.30-0.80
• Carbon: 0.06 max.
• Manganese: 0.80 max.
• Silicon: 1.00 max.
• Sulfur: 0.04 max.
• Phosphorus: 0.04 max.
• Iron: Balance

Specs

• AMS 5221
• AMS 5223
• AMS 5225

Characters

• Good plasticity in solution status
• Easy to process and shape
• Low temperature coefficient of elastic modulus
• High mechanical quality factor
• Good wave speed consistency
• High strength
• High elastic modulus
• Low Linear expansion coefficient
• Good corrosion resistance
• Small elastic aftereffects and hysteresis

Applications

• Spring
• Bourdon tube
• Sensor
• Watch part
• Diaphragm
• Capsule
• Corrugated pipe
• Vibrating cylinder

Forms of supply

•  Forgings
•  Ring
•  Plate
•  Sheet
•  Strip
•  Round bar
•  Wire
•  Tube
•  Capillary
