Haynes 188 High Nickel Alloys Forgings AMS 5772 UNS R30188 CoCr22NiW

Haynes 188 Nickel Cobalt Alloy with Excellent High-Temperature Strength

HAYNES 188 is a cobalt-nickel-chromium-tungsten alloy that combines excellent high temperature strength with very good resistance to oxidizing environments up to 1095°C for prolonged exposures, and excellent resistance to sulfate deposit hot corrosion. It is readily fabricated and formed by conventional techniques, and has been used for cast component. Other attractive features include excellent resistance to molten chloride salts, and good resistance to gaseous sulfdation.

Heat Treatment of HAYNES 188
HAYNES 188 is furnished in the solution heat treated condition. Solution heat-treated at 1163-1191°C and rapidly cooled or water quenched for optimal properties. Annealing at temperatures below the solution heat-treating temperature will produce some carbide precipitation inside and may affect the alloy’s properties.

Chemical composition



Forms and Sizes of Supply at XUNSHI

•  Round bar: Φ4~Φ300mm
•  Cold rolled sheet: thickness 0.5-4mm, width: 500-1200mm
•  Hot rolled sheet/plate: thickness 4-40mm, widht: 500-1200mm
•  Cold rolled strip: thickness: thickness: 0.05-1mm, width: 10-400mm
•  Capillary: min. O. D.:0.8mm, wall thickness: 0.05mm
•  Forged ring: O.D. less than 300mm
•  Rolled ring: O.D less than 3000mm


Spec of HAYNES 188 (UNS R30188)

•  Sheet, Plate & Strip AMS 5608
•  Billet, Rod & Bar AMS 5772
•  Forgings AMS 5772

About XUNSHI
Suzhou Xunshi New Material Co. Ltd- referred as XUNSHI hereafter, is a professional manufacturer of high-performance alloy products. XUNSHI is engaged in supplying high quality and cost-effective Superalloy, Anti-Corrosion Alloy, Precision Alloy, Special Stainless Steel and Magnetostrictive Material to customers worldwide.

Why XUNSHI

· Highly experienced in alloy industry

· Top experts of industry in China

· Advanced technology and process from top famous institutes in China

· Advanced devices through whole production and inspection process

· Strict quality control system

· Company motto: best service, most value

· Smart sales policy

Service Items of XUNSHI

· Non-standard product research and pre-production

· Fabrication of products

· Cutting, splitting for sheets and plates in stock

· Heat treatment (Solution treatment, aging harden treatment, anneal, spring temper, quench etc.)

· Surface finish (peeling, gridding, polishing)

· Logistics service

· Customized packing service (also for exporting)

· Import and export (XUNSHI is certificated)

· Document translation

· Hard-to-find material sourcing

Customers of XUNSHI
Customers of XUNSHI are all over China (Taiwan and Hong Kong included). And we are exporting to USA, Canada, Italy, UK, Poland, Greece, Russia, Turkey, Iran, Israel, South Africa, South Korea, North Korea, India, Argentina, and Brazil and so on. Customers from 30+ countries trust us.

Where is XUNSHI

A- XUNSHI is in Huaqiao, Kunshan, 215332 China, which is very closed to Shanghai.

B- Xunshi is around 80KM from Shanghai Pudong International Airport (PVG).

C- 20KM from Shanghai Hongqiao Airport

D- 20KM from Shanghai Hongqiao Railway Station

E- You can contact XUNSHI sales for a pickup service.
