Nimonic 80A Nickel Chromium Alloy Cold Rolled Strip for Temperatures up to 815 Degree

Temperatures 815°C Cold Rolled Strip W.Nr. 2.4631 Nickel-Chromium Alloy

W.Nr. 2.4631 is a wrought, age-hardenable nickel-chromiumalloy, strengthened by additions of titanium, aluminum and carbon, developed for service at temperatures up to 815°C (1500°F). It is produced by high-frequency melting and casting in air for forms to be extruded.
Electroslag refined material is used for forms to be forged. Vacuum refined versions are also available.

W.Nr. 2.4631 (Nimonic 80A) has been replaced by the Nimonic 90 and Inconel X-750, but is still widely used in nuclear power field due to its low cobalt content.

Chemical composition

Characters

Good creep resistance performance at temperature 650°C~850°C.

Good resistance to oxidation at temperature 650°C~850°C

Good cold and hot work performance

Good resistance to fatigue in serve work conditions

Application

Gas turbine components such as blades, rings and plates, etc..

Bolts used in temperature and stress limit

Combustion engine exhaust valve and other high strength parts.

Nuclear boiler tube bracket,

High temperature springs

Equal grades of W.Nr. 2.4631

GH4080A(GH80A)

W.Nr 2.4952

UNS N07080

Nicrofer 7020 Ti

NiCr20TiAl

Density: 8.15g/cm3

Magnetic performance: Non-magnetic

Form of supply

Hot forged bar, hot-forged rods, cold-drawn rods, hexagonal rods, ring parts, hot-rolled plates, cold-rolled plates, cold-rolled strip and various non-standard forgings.
