High Magnetic Saturation 1J27 Soft Magnetic Alloy Cold Rolled Strip Wire Rod
| Place of Origin | China |
|---|---|
| Brand Name | XUNSHI |
| Certification | ISO 9001:2015 |
| Model Number | 1J27 |
| Minimum Order Quantity | 20kg |
| Price | Negotiable |
| Packaging Details | Playwood case |
| Delivery Time | 35-40 days |
| Payment Terms | T/T |
| Supply Ability | 500 kg per week |
Product Details
| Equal Grade | HiperCo27, Vacofulx27, FeCo27, K92650 | Carbon | Max 0.025 |
|---|---|---|---|
| Character | High Magnetic Saturation | Forged Round Bar | Diameter 20-500mm |
| Product Name | Soft Magnetic Alloys | Package | Playwood Case |
| High Light | Cold Wire Soft Magnetic Alloys,Soft Magnetic Alloys Cold Rolled Strip,Soft Magnetic Alloys 1J27 |
||
Product Description
High Magnetic Saturation 1J27 Soft Magnetic Alloy Cold Rolled Strip Wire Rod
1J27 is a Soft Magnetic Alloy in China standard, the main component of this alloy is 27% cobalt, the rest being other elements such as Fe and Ni, Cr, 1J27 alloy is one of XUNSHI's featured products.
Chemical compostions(Weight Percent)
| C | ≤0.030 |
| Mn | ≤0.40 |
| Si | ≤0.35 |
| P | ≤0.015 |
| S | ≤0.015 |
| Cr | ≤0.75 |
| NI | ≤0.75 |
| Co | 26.5-28.5 |
| V | ≤0.35 |
| Fe | Balance |
The magnetic properties of the 1J27 samplse after the heat treatment
| Grade | Forms | Magnetic induction strength (T) in different magnetic field strength (A/m) |
Orthopedic force Hc(A/m) |
||||
| B2400 | B4000 | B8000 | B12000 | B16000 | |||
| Not less than | Not greater than | ||||||
| 1J27 | Cold rolled strip | 1.75 | 1.87 | 2.03 | 2.12 | 2.17 | 280 |
| 1J27 |
Cold wire Hot rolled flat Hot rolled rod |
1.05 | 1.10 | 1.75 | 1.95 | 2.10 | 300 |
Characters
High magnetic saturation
Good mechanical toughness
Good ductility
High saturation induction
High curie temperature: 925 °C
Equal grades
HiperCo27, Vacofulx27, FeCo27, K92650
The forms of available for the Soft Magnetic Alloys 1J27, 1J21, 1J22
Cold rolled strip, wire, hot rolled flat, forged round rod, non-standard forgings, etc.
