HYMU80 Soft Ferromagnetic Materials High Initial Permeability 0.04-5.0mm Thickness

China HYMU80 Soft Ferromagnetic Materials High Initial Permeability 0.04-5.0mm Thickness supplier
HYMU80 Soft Ferromagnetic Materials High Initial Permeability 0.04-5.0mm Thickness supplier HYMU80 Soft Ferromagnetic Materials High Initial Permeability 0.04-5.0mm Thickness supplier

Large Image :  HYMU80 Soft Ferromagnetic Materials High Initial Permeability 0.04-5.0mm Thickness

Product Details:

Place of Origin: China
Brand Name: AIWEN
Certification: ISO 9001:2015
Model Number: HYMU80

Payment & Shipping Terms:

Minimum Order Quantity: 20kg
Price: Negotiable
Packaging Details: Plywoode case
Delivery Time: 30-35 days
Payment Terms: T/T
Supply Ability: 1000 kg per month
Contact Now
Detailed Product Description
Application: Shielding Thickness: 0.04-5.0mm
Width: 10-240mm Denstiy: 8.74 G/cm3
Product Name: Soft Magnetic Alloys Package: Plywoode Case

HYMU80 Soft Magnetic Shielding Alloy Strip with High Initial Permeability



HYMU80 is a FeNi soft magnetic alloy with very high initial permeability.

HyMu 80 is suitable for applications across a broad spectrum of applications. Featuring high permeability with low hysteresis loss, the material’s shielding properties make it a suitable option for protecting electronic components against stray or low-frequency magnetic fields.

HYMU80 is widely used in magnetic shielding applications, isolating electronic components against magnetic interference for optimal functionality.



A-ONE ALLOY has rich experience of supplying HYMU80 in cold rolled strip.



Thickness range: 0.04~5.0mm

Width: 10~240mm



Chemcial composition (Nominal)
0.02 C, 0.50 Mn, 0.35 Si, 80.00 Ni, 4.20 Mo, Bal. Fe



Specifications:

MIL-N-14411C Composition 1, ASTM A-753-78



Density: 8.74g/cm3
