Thickness 0.05~2.0mm Soft Magnetic Alloys 1J50 with High Saturation Magnetic Flux Density

China Thickness 0.05~2.0mm Soft Magnetic Alloys 1J50 with High Saturation Magnetic Flux Density supplier
Thickness 0.05~2.0mm Soft Magnetic Alloys 1J50 with High Saturation Magnetic Flux Density supplier Thickness 0.05~2.0mm Soft Magnetic Alloys 1J50 with High Saturation Magnetic Flux Density supplier

Large Image :  Thickness 0.05~2.0mm Soft Magnetic Alloys 1J50 with High Saturation Magnetic Flux Density

Product Details:

Place of Origin: China
Brand Name: AIWEN
Certification: ISO 9001:2015
Model Number: 1J50

Payment & Shipping Terms:

Minimum Order Quantity: 50kg
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 30-35 days
Payment Terms: T/T
Supply Ability: 5000 kg per month
Contact Now
Detailed Product Description
Equal Grades: Ni50, Hyperm52, Alloy50, Magnifer 50 Thickness: 0.05~2.0mm
Width: 10~200mm Spec: GB/T 32286.1-2015
Certification: ISO 9001:2015 Product Name: Soft Magnetic Alloys

A-ONE ALLOY supplies 1J50 soft magnetic cold rolled strip with minimum thickness 0.05mm



1J50 is a widely used soft magnetic alloy in China. It  is used where high initial permeability, maximum permeability, and low core loss is needed.



Density: 8.2g/cm3

Curie point: 500°C

Saturation magnetostriction: 25 ppm



Applications

Transformer cores, highly efficient motors, shielding, and specialized electronic devices, such as LF power transducers, chokes, relay parts, solenoids & oscillators.



Chemical composition

Element C P S Cu Mn Si Ni Fe
Weight(%) 0.03 max. 0.020 max. 0.020 max. 0.20 max. 0.30~0.60 0.15~0.30 49.0~51.0 Balance



Heat treatment

1100°C~1180°C, held for 3~6 hours,  cooled to 600°C at a speed below 200°C/h , then cooled to below 300°C at a speed of no less than 400°C/h. Take out from furnace.



The parts heat treated should be handled with care, no vibration, no squeezing, no impacting. Or the magnetic properties will be worse.
