Strip Wire Round Bar Soft Magnetic Alloy 1J85 High Saturation

large.img.alt
small.img.alt

Large Image :  Strip Wire Round Bar Soft Magnetic Alloy 1J85 High Saturation

Product Details:
Place of Origin: China
Brand Name: XUNSHI
Certification: ISO9001
Model Number: 1J85
Payment & Shipping Terms:
Minimum Order Quantity: 30kg
Price: Negotiable
Packaging Details: Plywood case
Delivery Time: 30-35 days
Payment Terms: T/T
Supply Ability: 5000kg per month
Detailed Product Description
Product: Soft Magnetic Alloy Grade: 1J85
Forms Of Supply: Bar, Wire, Strip, Forging, Plate, Pipe Brand: XUNSHI
Certification: ISO9001 Country Of Origin: China
High Light:

Soft Magnetic Alloy 1J85

,

Bar Soft Magnetic Alloys

,

Strip Soft Magnetic Alloys

Soft Magnetic Alloy 1J85



XUN SHI NEW MATERIAL CO LTD is one of the best soft magnetic alloy 1j85 manufacturers and suppliers in China,we are experienced of supplying 1J85 soft magnetic alloy in forms of strip, wire, round bar and so on. Our customers are from worldwide and they trust us after the cooperation for years.



1J85 has high initial permeability and high saturation permeability and low coercive force in low-intensity magnetic field.



Chemialc compositions

Grade Chemical elements
C S P Mn Si Ni Mo Cu Fe
1J85 ≤0.03 ≤0.02 ≤0.02 0.3~0.60 0.15~0.3 79.0~81 4.8~5.2 ≤0.2 belance

Magnetic performance

Model

forms

grade



Thickness or diameter

In 0.4A/m Magnetic conductivityμ0.4

In 0.08A/m Magnetic conductivityμ0.08

Magnetic conductivityμm

(MAX)

Coercivity HC

Saturated magnetic induction strength Bs



A/m

T

not less than

not greater than

1J85

Cold rolled strip

0.1-0.19



37.5

187.5

1.6

0.7

0.2-0.34



50

225

1.2

0.7

0.35-1.0



62.5

312.5

0.8

0.7

1.1-2.5



50

187.5

1.2

0.7

0.1-0.19



62.5

225

1.2

0.7

0.2-0.34



75

250

1.0

0.7

0.35



68.8

325

0.7

0.7

hot rolled plate



3-22



37.5

125

1.6

0.7

hot rolled rod



8-100



37.5

125

1.6

0.7





The form of supply:

Cold rolled strip,hot rolled plate,hot rolled rod,hot forging rod, cold pulled wire, cold pulled pipe, capillary pipe, etc.



We can also process the components and provide heat treatment services according to the customer's drawings or specifications.

Other non-standard specifications can also be supplied through negotiation.
