INVAR 36 4J36 Low Expansion Alloy NILO 36

Place of Origin China
Brand Name XUNSHI
Certification ISO9001:2015
Model Number 4J36
Minimum Order Quantity 50kg
Price Negotiable
Packaging Details Plywood case
Delivery Time 30-35 days
Payment Terms T/T
Supply Ability 5000kg per week

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Equal Grade Invar36, Nilo36 Forms Of Supply Wire, Bar, Forging, Strip, Plate, Pipe, Tube, Capillary
Sepc YB/T 5241-1993 Curie Point 230°C
Product Name Low Expansion Alloy Certification ISO9001
High Light

4J36 Low Expansion Alloy

,

INVAR36 Low Expansion Alloy

,

Corrosion Resistant INVAR 36 Alloy

Leave a Message
Product Description



INVAR36(4J36)Low Expansion Alloy



4J36 is well known as Invar36 worldwide. It is a low expansion alloy with Curie point of around 230°C. When the temperature is below this point, 4J36 is magnetic and the expansion rate is very low. And when the temperature goes above this point, it becomes non-magnetic and the expansion rate goes bigger. 4J36 particularly useful in applications where minimum thermal expansion and high dimensional stability is required, such as in precision instruments like optoelectronic devices, optical and laser benches, electronics, and other kinds of scientific



Chemical composition

Element C P S Si Mn Ni Fe
Weight(%) 0.05 max 0.020 max 0.020 max 0.03 max 0.2~0.6 35.0~37.0 Rem



Similar Grade

Invar 36, NILO 36, Pernifer 36, 4J36, EN 1.3912, UNS K93600, UNS K93603, Werkstoff 1.3912



Line expansion coefficient

Standard:α1(20-100°C)≤1.5x10-6/°C



Physical property

Density:8.1g/cm3

Resresistivity:0.78μΩ·m

Curie temperature:230°C



Character

  • Low expansion rate up to 500°F
  • Readily weldable
  • Corrosion resistance in the atmosphere, fresh water and sea water
  • Good hot and cold processing performance
  • Good abrasive performance

Application

  • Cathode Ray Tubes
  • Telecommunications
  • Aeronautical and aerospace engineering
  • Cryogenic engineering (liquefied natural gas tankers)

Forms of supply

Wire, bar, forging, strip, plate, pipe, tube, capillary



INVAR 36 4J36 Low Expansion Alloy NILO 36 0INVAR 36 4J36 Low Expansion Alloy NILO 36 1

INVAR 36 4J36 Low Expansion Alloy NILO 36 2INVAR 36 4J36 Low Expansion Alloy NILO 36 3
