C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant

C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant
C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant

Large Image :  C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant

Product Details:
Place of Origin: China
Brand Name: XUNSHI
Certification: Rohs
Model Number: Hastelloy C276
Payment & Shipping Terms:
Minimum Order Quantity: 50kg
Price: Available per request
Packaging Details: Wooden case
Delivery Time: 25-35 days
Payment Terms: T/T
Supply Ability: 50 Ton per month
Detailed Product Description
Product Name: Corrosion Resistant Nickel-Based Alloy Equal Grade: NS3304,00Cr16Ni60Mo16W4,UNS N10276,W.Nr.2.4819,NC17D.Alloy C276,NS334(China)
Forms Of Supply: Forging, Bar, Wire, Tube, Pipe, Strip, Plate, Fastner, Powder, Capillary Stock Items: Forging Round Bar
Fabrication Service: Yes Heat Treatment Service: Solution Treatment, Age Hardening Treatment
Delivery Status: Black Or Bright Size: Customized
High Light:

Corrosion Resistant Hastelloy Alloy

,

Nickel Based Hastelloy Alloy

,

NS3304 Hastelloy Alloy

Hastelloy C276 Corrosion Resistant Nickel-based Alloy



Hastelloy C276 alloy is one of the most well known corrosion resistant alloys, and that was introduced in 1965,after 1970 using off-furnace refining (AOD,VOD) production to obtain ultra-low carbon and high purity. In order to reduce the disadvantages of consolidation heat treatment after welding or thermoforming, except for reducing carbon content, also the silicon content in the alloy reducing to 0.08%. Reducing the carbon content can reduce the amount of the carbon out quantity in the alloys, reducing the silicon content could reduce the amount of precipitation between metals in alloys, so that can achieve the purpose of increasing intercorrosion resistance of alloy. At the same time, the plasticity, toughness and processing properties of the alloy were improved.



Chemical composition is (%)

Mo Cr Fe W Co C
15.0-17.0 14.5-16.5 4.0-7.0 3.0-4.5 ≤2.5 ≤0.010
Si Mn V P S Ni
≤0.08 ≤1.0 ≤0.035 ≤0.040 ≤0.03 belance



Characters of the Hastelloy C276

  • Excellent corrosion resistance in reducing environments
  • Exceptional resistance to strong solutions of oxidizing salts, such as ferric and cupric chlorides
  • High nickel and molybdenum contents providing good corrosion resistance in reducing environments
  • Low carbon content which minimizes grain-boundary carbide precipitation during welding to maintain resistance to corrosion in heat-affected zones of welded joints
  • Resistance to localized corrosion such as pitting and stress-corrosion cracking
  • One of few materials to withstand the corrosive effects of wet chlorine gas, hypochlorite and chlorine dioxide

Applications of Alloy 276

  • Pollution control stack liners, ducts, dampers, scrubbers, stack-gas reheaters, fans and fan housings
  • Flue gas desulfurization systems
  • Chemical processing components like heat exchangers, reaction vessels, evaporators, and transfer piping
  • Sour gas wells
  • Pulp and paper production
  • Waste treatment
  • Pharmaceutical and food processing equipment



Forms available at XUNSHI

Bar, Wire, Tube, Pipe, Plate, Strip, Forging



Equal grades

NS3304,00Cr16Ni60Mo16W4,UNS N10276,W.Nr.2.4819,NC17D.Alloy C276,NS334(China)





Please feel free to contact us for enquiry.

Thank you.



C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant 0C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant 1

C276 NS3304 Nickel Based Hastelloy Alloy Corrosion Resistant 2
